Lc To Lc Patch Cord
Item: LC To LC Patch Cord DX CPRI patch cable 7.0mm
- Product Introduction
CPRI fiber patch cable for the new generation wireless base stations (WCDMA/TD-SCDMA/WiMax/GSM). Such LC To LC Patch Cord DX CPRI patch cable 7.0mm can be meet the FTTA (fiber to the top of the tower) program requirements for outdoor environment conditions and adverse weather conditions. Especially in the 3G, 4G, and WiMax base stations and fiber-optic distributed zoom technology, CPRI fiber patch cable are rapidly becoming the standard connector interface.
Patch Cord DX LC To LC patch cable 7.0mm Specifications:
|
ITEM |
PARAMETER |
|
Connector type |
LC, SC, FC, ST, E2000 |
|
Insertion Loss |
<0.3dB |
|
Return Loss |
SM>50dB,APC>60dB,MM>35dB |
|
Repeatability |
<=0.1 |
|
Interchangeability |
<=0.2dB |
|
Durability |
<=0.2dB |
|
Fiber Length |
1m, 2m…any length optional. |
|
Length and tolerance |
10cm |
|
Operating Temperature |
-20C ~ +85C |
|
Storage Temperature |
-20C ~ +85C |
Cable Parameters
|
Fiber Count |
2F |
|||
|
OD (mm) |
Buffered |
0.87±0.05mm |
||
|
2.0mm simplex cable |
2.0±0.05mm |
|||
|
7.0mm cable |
6.8-7.0mm |
|||
|
Thickness(mm) |
Buffered |
0.3±0.05mm |
||
|
2.0mm simplex cable |
0.25±0.05mm |
|||
|
7.0mm cable |
0.65±0.05mm |
|||
|
Nominal weight(kg/km) |
42 |
|||
|
Max tensile Strength(N) |
Short-term |
400 |
||
|
Long-term |
200 |
|||
|
Min Bending Radius(mm) |
Dynamic |
20D |
||
|
Static |
10D |
|||
|
Max Crush Resistance (N/100mm2) |
Short-term |
1000 |
||
|
Long-term |
300 |
|||
|
Material |
Buffered |
PVC |
||
|
2.0mm simplex cable |
LSZH |
|||
|
7.0mm cable |
LSZH |
|||
|
Color |
Black |
|||
|
Strength Member |
Aramid yarn |
|||
|
Environmental Protection |
RoHS COMPLIANT |
|||
|
Temperature range |
Storage or transportation |
-20~70℃ |
||
|
Operation |
-20~70℃ |
|||
|
Installation |
0~60℃ |
|||
Features of LC To LC Patch Cord DX CPRI patch cable:
- Open bulkhead for easy access to SFP
- Positive mechanical feedback to operator when fully mated
- One-hand mating
- Plug tolerance free design, fully free floating on Z-axis
- No Cable buckling during or after installation
- Cost effective metal die cast bulkhead
- Field installable version available
- Waterproof, dust proof and corrosion resistant
- Good mechanical and environmental characteristics;
- Flameretardant characteristics meet the requirements of relevant standards;
- Themechanical characteristics of jacket meet the requirements of relevant standards
- Soft,flexible, water blocked, UV resistant, easy to lay and splice, and with big capacity data transmission;
- Meet various requirements of market and clients
- Bulkhead cutout allows for removal of transceiver through the bulkhead (no need to open PRH for transceiver replacement)
- Robust bayonet locking for easy, fast, and secure mating
Applications:
- 3G,4Gbase station used
- Aerospace& Defense
- Equipment diagnosis
- FTTA, FTTP, FTTX, WIMAX
- BBU, RRU, RRH, LTE
