Team & Service
Our team is a dynamic,Quickly respond to customer needs, experienced technical team, provide design and customization services.
Wide Range of Applications
Our products are widely used in FTTH (Fiber to the Home) and FTTA (Fiber to the Antenna) applications.
Our Certificates
We have established a quality assurance system compliant with ISO9001 standards. Our products are strictly tested according to IEC, GR-326-Core, GR-3120-Core, GR-771-Core, and GR-1221-Core standards to ensure superior performance and reliability.
Broad Market
Our products are exported to a wide range of Market layout in Asia, Europe, Middle east, North America, South America, Africa.Products are exported over 50 countries, and are widely recognized by customers.
Single Mode Fiber Patch Cables (SM Fiber Patch Cables)
Single mode fiber patch cables, also known as SM fiber patch cables, are best suited for long-distance communication. Their thin glass fiber optic cable core permits light to travel directly along the fiber, facilitating clear data transmission over distances up to 100 kilometers without significant loss.
Multimode Fiber Patch Cables
Multimode fiber patch cables are optimized for shorter distances and high data volumes, making them ideal for internal network connections within buildings such as data centers or office setups. The larger core size of these cables allows for multiple light paths, supporting quick and efficient data transfer over distances typically less than 2 kilometers.
Armored Fiber Patch Cables
For environments prone to physical hazards, armored fiber patch cables provide extra protection. These cables are equipped with a durable, protective layer, safeguarding against physical damage from external pressures, such as industrial machinery or environmental impacts.
Transmission speed. Compared with copper cables, fiber optic patch cables have a much higher transmission speed. The transmission speed is up to 400Gbps for single-mode fiber cables and 100Gbps for multimode OM4 fiber cables.
Transmission distance. Fiber optic patch cables can be connected to devices far away from each other because they are made of optical fibers that can be transmitted very far in the air or underwater. For example, multimode fiber cables can be extended up to 2 kilometers, while single-mode fiber cables can be extended up to 160 kilometers under ideal conditions.
Low attenuation rate and high immunity to noise. Fiber optic patch cords are immune to electromagnetic interference (EMI) and radio frequency interference (RFI). In addition, they have the lowest attenuation loss among all the types of cable connectors, which makes them more reliable than copper cables.
Fiber cable strands are Tiny. It has the same diameter as human hair. Their data transmission capabilities much outweigh those of their copper counterparts. Regular copper cable is four times wider and only transmits a fraction of the data. Fiber cable is lighter, more flexible, and takes up less room (and therefore easier to manage). The extra space allows for more significant cooling, more accessible access to the equipment it connects to, and a more pleasant design.
|
Conector |
FC, SC, LC, ST, MU, E2000, LSZH... |
|
|
Fiber model |
SM |
G652D, G657A1, G657A2 |
|
MM |
OM1, OM2, OM3, OM4, OM5 |
|
|
Cable Dia |
Ø0.9mm, Ø2.0mm, Ø3.0mm |
|
|
Strength Member |
China aramid yarn, Dupont kelvar yarn |
|
|
Jacket |
PVC, LSZH, OFNR, PE, TPU |
|
|
Core number |
Simplex, Duplex, Multicore |
|
|
Length |
1, 2, 3, 5, 10m...or customized |
|
PC Fiber Patch Cable
PC fiber patch cable refers to the fiber patch cord that is polished in the physical contact style. It is the most commonly found polish type on OM1 and OM2 multimode fiber.
UPC Fiber Patch Cable
UPC fiber patch cable refers to the fiber patch cord that is polished in the Ultra Physical Contact style. It is an advancement of the PC fiber patch cable with a better surface finish after extensive polishing and a lower return loss than the PC structure, approximately -50dB or higher.
APC Fiber Patch Cable
It refers to a fiber patch cord with an APC connector. APC Connector is an abbreviation for Angle Polished Connector. Take note of the angled tip of the white ceramic. This angle eliminates back reflections, which significantly reduce the performance of any analog fiber optic system, such as CATV and satellite.
Data Centers
Fiber optic patch cables are extensively used in data centers for connecting servers, switches, routers, and other networking equipment. Their high bandwidth and low latency make them ideal for high-speed data transmission in that environment.
Telecommunications
Telecom networks utilize fiber optic patch cables for transmitting voice, video, and data signals. In shorter distances within telecom facilities or between buildings, these cables are used for interconnecting equipment.
Local Area Networks (LANs)
Fiber optic patch cables are increasingly being used in LAN environments, especially in situations where high bandwidth and reliability are crucial. They connect network switches, routers, and other devices within office buildings or campuses.
Industrial Automation
Fiber optic patch cables are used in industrial automation systems for transmitting data between various sensors, controllers, and machinery. They offer high reliability and resistance to EMI, making them suitable for harsh industrial environments.
Broadcasting and Audiovisual Systems
In broadcasting studios, theaters, and other AV environments, fiber optic patch cables transmit high-definition video, audio, and control signals between different equipment such as cameras, monitors, and video switchers.
Military and Aerospace Applications
Fiber optic patch cables are used in military and aerospace applications where high-speed, secure, and reliable data transmission is critical. They are employed in communication systems, surveillance equipment, and avionics.
Healthcare and Medical Imaging
In healthcare facilities, fiber optic patch cables are used in medical imaging equipment such as MRI machines, CT scanners, and ultrasound devices for transmitting high-resolution images and data quickly and reliably.
Education and Research Institutions
Fiber optic patch cables are used in educational and research institutions for connecting networking equipment, laboratory instruments, and high-performance computing clusters.
We're professional fiber patch cord manufacturers and suppliers in China, specialized in providing high quality custom service. We warmly welcome you to buy cheap fiber patch cord from our factory.
