Team & Service
Our team is a dynamic,Quickly respond to customer needs, experienced technical team, provide design and customization services.
Wide Range of Applications
Our products are widely used in FTTH (Fiber to the Home) and FTTA (Fiber to the Antenna) applications.
Our Certificates
We have established a quality assurance system compliant with ISO9001 standards. Our products are strictly tested according to IEC, GR-326-Core, GR-3120-Core, GR-771-Core, and GR-1221-Core standards to ensure superior performance and reliability.
Broad Market
Our products are exported to a wide range of Market layout in Asia, Europe, Middle east, North America, South America, Africa.Products are exported over 50 countries, and are widely recognized by customers.
Direct Buried Cables
In the absence of duct infrastructure, cables can be buried directly into the ground in a trench or using a vibratory plow.
Duct Cables
Duct cables (or conduits) offer a highly protective environment for fiber-optic cables. They are typically buried, and then the cables are air-blown, jetted, pulled, or pushed into the duct.
Loose Tube Cable
Loose tube cable provides stable performance over a wide temperature range, small, high fiber count cables, and is compatible with any telecommunications-grade optical fiber.
Ribbon Cable
Ribbon cables offer higher fiber counts and greater fiber density than any other cable construction designed for the outside plant (OSP), four times the highest-fiber-count loose tube cable.
Micro Duct Cable
The micro duct is the miniaturized plastic conduit that subdivides internal duct space into smaller compartments into which micro cable can be installed by blowing, jetting, or pushing.
Drop Cable
Drop cable is the cable that runs from the distribution point or cable to the subscriber/user.
Underwater Cable
The casing material has good hydrolysis resistance and high strength; the cable paste is filled to provide key protection for the optical fiber.
Armored Cable
Armored cable is a kind of outdoor cable with protective armor wrapped around the fiber cable core.
|
Type |
Attenuation(+20℃) |
Bandwidth |
Numerical aperture |
||||
|
@850nm |
@1300nm |
@1310nm |
@1550nm |
@850nm |
@1300nm |
||
|
G.652 |
--- |
--- |
≤0.36dB/km |
≤0.22dB/km |
--- |
--- |
--- |
|
G.655 |
--- |
--- |
≤0.40dB/km |
≤0.23dB/km |
--- |
--- |
--- |
|
50/125µm |
≤3.3dB/km |
≤1.2dB/km |
--- |
--- |
≥500MHz·km |
≥500MHz·km |
0.200±0.015 NA |
|
62.5/125µm |
≤3.5dB/km |
≤1.2dB/km |
--- |
--- |
≥200MHz·km |
≥500MHz·km |
0.275±0.015 NA |
|
Model |
Fiber |
Tube count |
Filling |
Weight |
Tension |
|
GYXS/GYXTW-2~12Xn |
2~12 |
82 |
600/1500 |
300/1000 |
10D/20D |
|
GYXS/GYXTW-14~24Xn |
14~24 |
127 |
|||
|
GYXS/GYXTW-2~12Xn |
2~12 |
124 |
1000/3000 |
||
|
GYXS/GYXTW-14~24Xn |
14~24 |
147 |
Resistance to harsh environments
Outdoor cables are designed to withstand extreme weather conditions, making them suitable for deployment in areas with high moisture, temperature variations, or exposure to UV radiation.
Long-distance connectivity
Outdoor cables are capable of providing reliable communication over long distances, making them ideal for inter-building or long-haul connections.
Physical protection
The additional layers or armors in outdoor cables provide protection against physical damage, ensuring the integrity of the fiber strands.
Burial or aerial installation methods
Outdoor cables can be installed either by burying them underground or by using aerial methods, depending on the specific requirements and local regulations. Burial depths, conduit usage, and aerial support structures should be considered during the installation process.
Protection against environmental factors
Outdoor cables should be protected from moisture and extreme temperatures, as these can affect their performance and longevity. Proper sealing, waterproofing, and temperature protection measures should be implemented.
Grounding and bonding
Grounding and bonding outdoor cables are essential to prevent electrical hazards, protect against lightning strikes, and ensure proper signal transmission. Following proper grounding techniques and local electrical codes is crucial during installation.
Maintenance and inspection
Regular inspection and maintenance are necessary to identify and address any potential issues that may arise, such as damage from animals, vegetation, or vandalism. Periodic cleaning and testing help maintain optimal performance.
We're professional outdoor cable manufacturers and suppliers in China, specialized in providing high quality custom service. We warmly welcome you to buy cheap outdoor cable from our factory.
