Inline Fiber Enclosures

Your Professional Inline Fiber Enclosures Supplier

Glory Optical Communication Co., Ltd., located in Ningbo, China, has over 15 years of experience in the fiber optic communication and FTTx network industries. Our facilities include a modern production plant, a test center, and a business development department. The company specializes in the research and development of advanced optical cable structures, as well as customized services for optical cable splice closures, optical cable distribution boxes, and related products.

First 12 3 4 Last 1/4

Why Choose Us

Team & Service

Our team is a dynamic,Quickly respond to customer needs, experienced technical team, provide design and customization services.

Wide Range of Applications

Our products are widely used in FTTH (Fiber to the Home) and FTTA (Fiber to the Antenna) applications.

Our Certificates

We have established a quality assurance system compliant with ISO9001 standards. Our products are strictly tested according to IEC, GR-326-Core, GR-3120-Core, GR-771-Core, and GR-1221-Core standards to ensure superior performance and reliability.

Broad Market

Our products are exported to a wide range of Market layout in Asia, Europe, Middle east, North America, South America, Africa.Products are exported over 50 countries, and are widely recognized by customers.

Features

1). High quality PC, ABS, PPR material optional, can ensure harsh conditions such as vibration, impact, tensile cable distortion and strong temperature changes.

2). Solid structure, perfect outline, thunder, erosion and adding resistance.

3). Strong and reasonable structure with mechanical sealing structure, can be opened after sealing and cab be reused.

4). Well water and dust proof, unique grounding device to ensure the sealing performance, convenient for installation.

5). The splice closure has a wide application range, with good sealing performance, easy installation, produced with high strength engineering plastic housing, with anti-aging, corrosion resistance, high temperature and high mechanical strength and so on.

Product Description

Product Name	96 core fiber optic splice closure
Material	PC/ABS/PP
Dimension (mm)	430(l)190(w)110(h)mm
Colour	Black
Max Capacity	96core
Maximum install tray Number	4
Ports	2 inlet 2 outlet
Installation method	Wall mounted or pole mounted

Advantages of Inline Fiber Enclosures

1

Reliability

It provides a reliable sealing solution that maintains a secure grip for a long time.

2

Waterproof

It guarantees a waterproof seal to prevent moisture and potential water damage.

3

Easy to install

The installation process is relatively simple and only requires basic training for technicians.

4

Cost-effectiveness

The manufacturing cost is low compared to mechanical fiber closures.

Specification

Model No.	GPJ09-6820
Style	Inline/Horizontal
Dimensions (L×W×H)	396×200×126 mm
Material	Polymer Modified Plastics
Sealing Type	Mechanical Seal
Protection Grade	IP68
Cable Ports	Inlet	3	Φ8 - Φ20 mm
	Outlet	3
Fiber Splice Capacity	Min 12, Max 96
Tray Capacity	24
Tray Count	4
Weight	2.5 - 2.7 kg
Application	Aerial/ Wall Mounting/ Duct Mounting
Packing Type	Inner Carton		440×200×130 mm (1 PCS)
	Outer Carton		460×420×420 mm (6 PCS)

Connection steps of Inline Fiber Enclosures

01

First, mount the fiber enclosure in an appropriate and secure location, such as racks or cabinets. Make sure that this work will be done on a clean and level work surface. If you choose the fully loaded fiber enclosure, just install it on your rack with specific tools. If your fiber enclosure is unloaded, please insert fiber adapter panels or cassettes into it. Then, fix the mounting plate in the right position.

02

Insert the fiber optic cables into the appropriate ports on the patch panel. Terminate the fibers onto connectors using a fiber cleaver for clean cuts if needed. Match the cable connectors to the correct adapter ports (LC, SC, or ST).

03

Test the fiber optic links using a fiber optic tester to ensure proper functionality. Once confirmed, organize and secure the cables using cable management tools to keep everything tidy and protected.

Applications Of Inline Fiber Enclosures

Fibre cable fusion splicing in pits, direct buried, aerial or pole mounting
Fibre cable joining or repairs
Fibre cable tap off and expressing

Packaging & Shipping

productcate-901-425

FAQ

Q: When would an inline splice of fiber optic cable be used?

A: Inline closures are used in applications where two identical cables are spliced and an inline closure saves space or when making repairs to damaged cables.

Q: Is it okay to splice fiber optic cable?

A: Since fusion splicing won't alter the fiber's structure, it is recommended for long-term fixes.

Q: Where is fiber optic cable most commonly used?

A: Internet communication
Applications. Optical fiber is used by telecommunications companies to transmit telephone signals, Internet communication and cable television signals. It is also used in other industries, including medical, defense, government, industrial and commercial.

Q: How many times can you splice fiber optic cable?

A: Can fiber optic cables be spliced multiple times? Fiber optic cables can be spliced multiple times if necessary. However, each splice point has the potential to introduce signal loss or reflections, which can degrade the overall performance of the cable.

Q: Can electricity travel through fiber optic cable?

A: Fiber optic cables are nonconductive. They don't conduct electricity. Therefore, they aren't used to transmit electricity from outlets or other sources to various devices. Fiber optic cables are specifically used to transmit data.

Q: How far can light travel through a fiber optic cable?

A: What is the maximum distance of fiber optic cable? Although the maximum distance of fiber optic cable is affected by both attenuation and dispersion, for most applications, the maximum distance of any type of fiber optic cable is around 62.14 miles (100 kilometers). However, some applications require longer distances.

We're professional inline fiber enclosures manufacturers and suppliers in China, specialized in providing high quality custom service. We warmly welcome you to buy cheap inline fiber enclosures from our factory.
