Fiber Optic Patch Cord
Model: SC/APC Hardened Pre-Connectorized OptiTap 5.0mm Drop Fiber Cable
OptiTap Drop Cable Outdoor Fiber Assemblies with Optitap Connector is a factory-terminated, environmentally sealed and hardened connectors. It’s connection solution for fiber to the home (FTTH) connectivity. It connects easily to terminals or receptacles and is ideal for direct burial, conduit, or aerial applications
- Product Introduction
SC/APC Hardened Pre-Connectorized OptiTap 5.0mm Fiber Drops Assemblies Fiber Optic Patch Cord provide a robust and sealed connection solution for fiber to the home (FTTH) connectivity. The hardened connector end incorporates an SC/APC type connection within a slim, sealed, threaded polymer housing allowing easy connection to either a multiport terminal or in-line extension receptacle. The SC/APC connector mates to a standard adapter, providing a common interface for FTTH applications.
The SC/APC connector, housed in a slim, sealed, threaded polymer casing, allows easy connection to a multiport terminal or in-line extension receptacle. It mates with a standard adapter for FTTH applications. The connector, available with flat drop or traditional round style OSP cables, is ideal for direct burial, conduit, or aerial applications.
Features
• Reduce welding, connect directly to achieve interconnection
• Factory terminated for high performance
• Hybrid (one end with an OptiTap Connector, one end with standard SC connector) available
• IP68 water and dust protection
• Cable design for aerial, direct-buried or duct installation
Application for Hardened Pre-Connectorized OptiTap Fiber Optic Patch Cord
• Fiber optic communications in harsh outdoor environments
• Outdoor communication equipment connection
• Waterproof fiber equipment SC port
• Remote wireless base station
• FTTX
Specification
|
Connector |
OptiTap SC/APC Connectors Male |
|
Polish |
APC-APC |
|
Fiber Mode |
9/125μm, G657A1 G657A2 |
|
Jacket Color |
Black |
|
Cable Diameter |
5.0±0.2mm |
|
Jacket Material |
LSZH |
|
Insertion loss |
≤0.3dB |
|
Return loss |
SM APC ≥ 60dB |
|
Wavelength |
SM:1310/1550nm |
|
Application |
Aerial, Direct Buried, Duct |
|
Operation Temperature |
-10 ~ +70°C |
|
Install&Storage temperature |
-40 ~ +70°C |
FAQ
Q: Are your trading company or manufacturer?
Q: Do you provide OEM service?
Q: :Can you provide free samples?
Q: How can you guarantee the quality?
Q: What is your delivery time?
