Cassette PLC Splitter: Efficient Signal Distribution for Fiber Optic Networks

The ABS Cassette Fiber Optic PLC Splitter with connector is named for its design, which incorporates a compact cassette module pre-installed with the splitter. This configuration simplifies installation and enhances overall cable management. It typically features one input port and multiple output ports, enabling the splitting of a single optical fiber signal into multiple channels. The cassette-based PLC splitter adopts a space-efficient design, making it ideal for installations with limited cabinet space. It is designed to fit neatly into standard cassette slots, reducing clutter while facilitating easy maintenance and future expansion.

Optical PLC Splitter with MPO/MTP Connectors for High-Density Networks​​

The MPO/MTP connector, when used in conjunction with an optical PLC splitter, offers several advantages for fiber optic networks. One of the primary benefits is its ​​high fiber density​​, which enables ​​more efficient space utilization​​. Additionally, the ​​push-pull design​​ of MPO/MTP connectors allows for quick and easy installation. The ​​precise alignment ensured by the ferrule design​​ minimizes signal loss and improves transmission quality. Furthermore, the multi-fiber configuration ​​not only​​ simplifies testing and troubleshooting ​​but also​​ enhances compatibility with various systems and equipment, ensuring versatility. Finally, integrating MPO/MTP connectors with optical PLC splitters can lead to ​​significant cost savings​​ due to their high-density capacity and simplified installation/maintenance processes.



Reliable and Rigorously Tested PLC Splitter with MPO/MTP Connector

The reliable and tested MPO/MTP fiber optic PLC splitter is a cutting-edge solution for efficient, high-performance fiber optic networks. The MPO/MTP connector interface ensures quick and easy installation, minimizing downtime and maximizing productivity. Moreover, the MPO/MTP connectors in the PLC splitter undergo rigorous testing to ensure reliability and performance. These components adhere to strict industry standards, guaranteeing consistent and accurate signal transmission. With its compact and durable design, the PLC splitter with MPO/MTP connectors is an ideal choice for telecommunications companies, data centers, and other industries requiring fast and reliable network connections.



Specifications:



1 Split Ratio and Configuration of PLC Splitter With MPO/MTP Connector

​​• Type​​: 1×8 PLC splitter cassette, utilizing planar lightwave circuit (PLC) technology for even signal distribution.

​​• Fiber Type​​: Single-mode, compliant with ITU-T G.657A1/G.652D standards for bend-insensitive performance.



​​2 Optical Performance​​

​​• Insertion Loss​​: ≤10.3 dB (typical at 1550 nm).

​​• Uniformity​​: ≤0.8 dB across all output channels.

​​• Return Loss​​: ≥55 dB (UPC/APC connectors).

​​• Wavelength Range​​: 1260–1650 nm (supports full spectrum for FTTH/PON applications).

​​• Polarization-Dependent Loss (PDL)​​: ≤0.3 dB.



​​3 Connector Specifications​​

​​• MPO Connector​​: Standard 12-fiber MPO/MTP interface for high-density connectivity.

​​• Durability​​: Rated for >1,000 insertion/extraction cycles.



​​4 Environmental and Mechanical Parameters​​

​​• Operating Temperature​​: -40°C to +85°C.

​​• Storage Temperature​​: -40°C to +85°C.

​​• Humidity Resistance​​: ≤85% relative humidity (non-condensing).



​​5 Certifications and Compliance​​

​​• Standards​​: Telcordia GR-1209/1221, RoHS, and ISO 9001/14001.

​​• Packaging​​: Compact metal or LGX-style cassette for easy integration into distribution frames or enclosures



Application of PLC Splitter With MPO/MTP Connector in Data Center



PLC Splitters with MPO/MTP Connectors ​​are​​ essential components in data center networks. They enable efficient optical signal distribution among network devices, including switches, optical transceiver ​​modules​​, and fiber optic patch panels, facilitating high-speed networking and reliable data transmission. Additionally, they play a crucial role in redundant network setups by distributing optical signals across redundant paths or devices ​​to maintain​​ uninterrupted operation ​​in case of​​ equipment failure. Overall, PLC Splitters with MPO/MTP Connectors provide critical support for the complex ​​infrastructure​​ of data centers, ​​enhancing​​ communication efficiency, data transfer, and network resilience.
