1x8 Fiber Optic Splitter



1x8 Fiber Optic Splitter LGX Cassette Module



1×8 Fiber Optic Splitter LGX Cassette Module feature low IL& PDL, high isolation suit for 1260nm~1650nm optical fiber signals' splitter and distributing in PON networks. 1×8 PLC Splitter SC/UPC with one input and 8 output, assembled with 9 units SC/UPC or SC/APC fiber optic connectors. 1×8 PLC SM Splitter SC APC use the G657A fiber and the max bending radius of the fiber is 15mm. 1×8 PLC Splitter SC APC Cassette Module directly with 2.0mm fiber terminals, tail length according to customer specified.



1x8 PLC splitter LGX Cassette Module apply to home wiring, engineering projects, corporate companies, fiber optic LAN. It has compact structure and good stability, and can be installed in various existing transfer boxes without leaving a lot of installation space. All-fiber structure, stable and fast, built-in high-quality chip, ensure uniform and stable light splitting, quick response without delay, which can meet the needs of different wavelengths. The fiber optic splitter is ABS plastic shell, with pit impact resistance, heat resistance and low temperature resistance.



Specifications:



Type	1x8 Fiber Optic Splitter LGX Cassette	Certification	CE, ISO, RoHS
Configuration Type	1X 8	Split Ratio	50/50
Return Loss	55dB	Temperature Dependent Loss	0.5dB
Operating Wavelength	1260nm-1650nm	Mode	Single mode
Dimensions	29X130X127mm (HxWxD)



Product Parameters



Item	1x8 Fiber Optic Splitter
Operating Wavelength(nm)	1260-1650
Connector	SC/FC/LC
Ferrule section	UPC/APC
Insertion loss(dB)	≤12.8
Loss uniformity(dB)	≤1.2
Return Loss(dB)	≥55
Polarization Dependent Loss(dB)	≤0.25
Directivity(dB)	≥55
Temperature correlation loss	≤0.5
-40~85ºC(dB)
Working Temperature(ºC)	-40~75
Storage Temperature(ºC)	-40~75



Features of 1x8 Fiber Optic Splitter:



• Widely wavelength.

• Small volume

• Large capacity

• Premium Fiber Splitter Guarantees Stable Transmission

• Low Insertion loss and PDL
• Compact Design
• Good channel-to-channel uniformity
• Wide Operating Wavelength: From 1260nm to 1650nm
• High Reliability and Stability



Applications:



In a ​​GPON-based FTTH network​​, the 1×8 LGX cassette Fiber Optic Splitter splits the downstream signal from the OLT (active device) into 8 channels, each connecting to an ONT at a subscriber's location. Simultaneously, upstream signals from ONTs are combined through the same module, enabling bidirectional communication with minimal loss.
