SCPC To SCPC Patch Cord
Model: Huawei Mini SC Pre-Connectorized Drop cable
The mini SC connector is a factory-terminated, environmentally sealed, and hardened connector designed to reduce the cost and time of drop cable deployment in optical access networks. The SC PC to SC PC Patch Cord is specifically designed to significantly reduce required drop cable installation time and is compatible with Huawei devices.
- Product Introduction
SC PC To SC PC Patch Cord HW Mini SC Pre-Connectorized Drop Cable
Huawei Compatible Mini SC pre-terminated optical drop cables (SC/PC to SC/PC Patch Cord) provide easy FTTx (Fiber-To-The-X) installation and termination using existing hardware and installation methods for drops to homes and businesses. The flat profile is compatible with existing wedge (P) clamps. This connector always comes with a 2.0mm × 5.0mm self-supporting drop cable, a 3.0mm indoor cable, or a 5.0mm round cable.
Mini SC assemblies provide a robust and sealed connection solution for fiber-to-the-home (FTTH) connectivity.
Specifications:
|
Application |
Aerial, Direct Buried, Duct |
|
Cable Type |
Outdoor Cable |
|
Fiber Type |
G657A1/G657A2/G657B3, customized |
|
Termination |
One end or both ends |
|
Product Type |
Drop Assemblies |
|
Connector A |
Huawei Mini SC APC Connector |
|
Connector B |
No connector, SC APC or Huawei Mini SC APC Connector |
|
Cable Length |
Customized |
|
Operation Temperature |
-40 °C to 70 °C (-40 °F to 158 °F) |
|
Insertion Loss |
≤0.2dB |
|
Return Loss |
≥55dB |
Features for SC PC To SC PC Pre-Connectorized Patch Cord:
• Provides superior weather resistance for FTTA and other outdoor applications.
• Allows flexibility to use factory-terminated assemblies, pre-terminated assemblies, or field-installed assemblies.
• Suitable for FTTA and outdoor temperature extremes; ensures functionality in harsh weather environments.
• Can be installed without special tooling.
• Threaded-style coupling.
• Provides bend protection for installation and long-term use.
• Faster network rollout and customer installations.
• 100% tested assemblies built in a controlled environment.
• Lower-cost deployment by utilizing plug-and-play solutions.
• Custom-built solutions with quick turnaround times.
Application:
FTTH, Outdoor Areas, Harsh Environment.
