Ftth Socket Panel
Item: Ftth Socket Panel
Model: GL- GPMB-E2
•Application for Wall hanging/table, 4 Cable inlet/outlet, Indoor type
•Compact size and Rational structure
• Pigtail and adaptor can be installed
FTTH Socket Panel also called FTTH Face plate, fiber face plate, fiber optical socket panel, is a type of FTTH terminal products for FTTH indoor application.
It is suitable for home or office to provide end users with optical access or data access.
- Product Introduction
FTTH Socket Panel GL- GPMB-E2 is is used as a termination point for the drop cable to connect with patch cable in FTTH indoor/outdoor application. It integrates fiber termination, storage and cable connection in one solid protection box. The splice tray is for splicing a fiber of raiser cable and the subscriber's drop cable through adaptor plate acting as interface.
Use premium grade fame resistant material, have reasonable bending radius for fiber protection, push type cover makes installation easy. We accept to customize logo on this panel.
The Composition of the FTTH Socket Panel are optic panel, plastic expansion screw and heat shrinkable sleeve(optional).
Specifications
|
Item Name |
FTTH Socket Panel GL- GPMB-E2 |
|
Size |
115×86×23mm |
|
Material |
ABS |
|
Max capacity |
2 Fibers |
|
Applicable Optical Cable Diameter(mm) |
2,3 or 2×3,2x5 drop cable |
|
Cable inlet/outlet port |
4 |
|
Adapter type |
SC simplex/LC duplex |
|
Radius of curvature of the fiber |
≥40mm |
|
Additional loss of fiber optic tray |
≤0.01dB |
|
Working temperature |
- 40℃ ~ + 70℃ |
|
Side pressure |
≥2000N / 10 cm |
|
Impact resistance |
≥20N.m |
Characteristics
• One SC or LC adapter interface
• Redundant fiber can be stored inside, easy to use and maintain
• reversible disk increases the distribution space with clear splicing and wiring, zone, the line crossing is reduced.
• Heat or mechanical splicing,Widely used, especially for multi-story and high rise buildings
• Fully enclosed FTTH Socket Panel,additional transparent cover at the outlet to achieve better dustproof effect
Applications
The FTTH socket box is used in the home or work area to complete the connection and port output of the dual-core optical fiber, which can fully meet the requirements of the bending length of the optical fiber, protect the incoming and outgoing optical fibers, and provide safe protection for the fiber core. Appropriate curvature size allows inventory of a small amount of excess optical fiber to realize FTTD (optical fiber to desktop) system application.
FAQ
What is the main function of FTTH Socket Panel?
The main function is to replace the fixed module and protect the cable at the information outlet, thereby generating a screen-like effect. Use SC flange and optical fiber quick connector, optical fiber jumper connection That is not the main product component that affects performance, but in the entire wiring system, it is one of the few products exposed on the surface.
