Fiber Cable Joint Box
Item: Fiber Cable Joint Box GL-S02
Inline Type 6-Port Mechanical Sealing Fiber Optic Splice Closure (FOSC), 96-Fiber Outdoor Model
- Product Introduction
6 Ports Inline Fiber Cable Joint Box
The Fiber Cable Joint Box is designed to protect fiber optic cable splices and joints. It features a rubberized seal for dust and weather resistance, a compact size, a dustproof and waterproof design, easy operation, and a reusable mechanical seal.
This inline fiber cable joint box is suitable for outdoor use, including aerial mounting or underground installation. Its operating temperature ranges from -40°C to 65°C.
The maximum capacity is 96 fibers for bundled cables and 144 fibers for ribbon cables. It includes a standard Fiber Optic Splice Closure for splicing and an FTTH Fiber Cable Joint Box for housing fiber optic splitters in FTTH Passive Optical Networks.
Specifications:
|
Model |
Fiber Cable Joint Box GL-S02 |
|
Type |
Inline type |
|
Number of Inlet/Outlet ports |
6 ports |
|
Cable Diameter |
2 ports×13mm, 2 ports×16mm, 2 ports×20mm |
|
Maximum Capacity |
Bunchy: 96 fibers; Ribbon: 144 fiber |
|
Capacity per Splice Tray |
Bunchy: single layer: 12 fibers; dual layers: 24 fibers; Ribbon: standard: 3pcs; max.: 6pcs |
|
Quantity of Splice Tray |
4pcs |
|
Body Material |
PC |
|
Sealing Material |
Thermoplastic rubber |
|
Assembling method |
Aerial, direct buried, pipelined, wall mounting, manhole |
|
Dimension |
320(L)×210(W)×85(H)mm |
|
Net Weight |
2.65~2.8KG |
|
Temperature |
-40℃~65℃ |
Features of Inline Fiber Cable Joint Box：
• User-friendly accessibility for setup, upkeep, and scalability requirements
• Robust environmental protection with superior moisture resistance and durability
• Pivoting fusion organizers enabling capacity upgrades without disrupting existing connections
• Supports common fiber optic cabling solutions meeting industry specifications
Application:
In Fiber-to-the-Home (FTTH) Passive Optical Networks (PONs), reliable connectivity and efficient fiber management are critical for delivering high-speed broadband services. The Inline Fiber Cable Joint Box plays a vital role in ensuring seamless fiber optic network deployment, protection, and maintenance. This compact yet robust device is designed to address challenges in fiber splicing, distribution, and environmental protection, making it indispensable in modern FTTH infrastructure.
