FPV Drone Fiber Optic Cable
Model: Anti-Interference FPV Drone Fiber Optic Cable for UAV, SM G657A2, Ranging from 3km to 30km, with Coil of Bare Optical Fiber
- Product Introduction
Anti-Interference FPV Drone Fiber Optic Cable for UAV
FPV Drone Fiber Module Flight distance 5/10/20/30KM for connector for uav accessories FPV Drone FPV optical fiber communication equipment, through optical fiber remote control and image transmission, is effective inanti-interference and suitable for use in places with weak signals.
The fiber optic diagram module uses fiber optic as the transmission medium, with fast transmission speed and strong stability to meet the transmission needs of large amounts of data. It is not affected by electromagnetic interference, prevents eavesdropping and theft, and can support wired signal transmission up to 50km.
Main features of the product
Stable, fast and anti-interference.
Specification.
|
FPV Drone fiber optic Reel Module |
||
|
Fiber length |
Net Weight |
Gross Weight |
|
3km |
300g |
560g |
|
5km |
500g |
790g |
|
10km |
950g |
1.27kg |
|
15km |
1.2kg |
1.55kg |
|
20km |
1.65kg |
2.03kg |
|
30km |
2.1kg |
2.51kg |
|
FPV Drone fiber optic Reel Module (With Built-in Sky Module) |
||
|
Fiber length |
Net Weight |
Gross Weight |
|
3km |
320g |
580g |
|
5km |
525g |
815g |
|
10km |
1.039 |
1.35kg |
|
15km |
1.31kg |
1.66kg |
|
20km |
1.76kg |
2.15kg |
|
30km |
2.22kg |
2.66kg |
FPV Drone Fiber Optic Cable is made of black ABS engineering plastic, featuring both high strength and lightweight characteristics (density 1.15-1.2g/cm³, meeting industrial-grade standards). It supports customizable lengths ranging from 3 to 30 kilometers, catering to diverse scene requirements. It is compatible with standard connectors such as FC, ST, SC, and LC, and is compatible with G657A2 bending-insensitive optical fibers (diameter 0.27-0.4mm), maintaining signal stability even in a tightly bent state.
The modular design, combined with self-lubricating drums and magnetic levitation tension control systems, achieves an optical fiber unfolding speed of 0.05-2m/s, and the rebound rate is less than 0.7% when suddenly stopped, significantly reducing the risk of entanglement in dynamic environments. It has passed the UL94 HB flame retardant certification and operates within a wide temperature range of -30°C to 75°C, ensuring stable operation in harsh weather or disaster sites.
Applications of FPV Drone Fiber Optic Cable
Power Inspection and Energy Exploration
Fiber-optic drones, leveraging their anti-electromagnetic interference (EMI) capabilities and ultra-long transmission distances (10–100 km), can penetrate complex environments such as high-voltage transmission lines and oil and gas pipelines.
They transmit high-definition images and sensor data in real time to pinpoint issues like line damage and insulator faultss.
For instance, in extremely cold regions, their low-temperature resistance (stable operation at -30°C) ensures efficient winter power repair. In oil exploration, fiber-optic transmission of ground-penetrating radar data enables resource exploration in remote areas.
Intelligent Agricultural Operations
By integrating multispectral sensors and optical fiber communication modules, UAVs perform precision pesticide application and crop growth monitoring.
Optical fibers' EMI resistance ensures stable data transmission in electromagnetically complex farmland (e.g., near high-voltage lines). Combined with AI algorithms for crop health analysis, this system achieves variable fertilization, reducing pesticide use by over 30%.
Film-Level Aerial Photography and Disaster Rescue
In film production, fiber-optic drones overcome signal limitations of traditional wireless transmission, enabling stable 4K/8K transmission in densely populated areas or electromagnetic-heavy environments (e.g., explosion sites).
During disaster rescue, their low-altitude penetration (5–50 m height) detects vital signs through rubble crevices. Thermal imaging data is relayed in real time via anti-interference fibers, enhancing survival rates during critical rescue windows.
