Fiber Splice Closure
Model:Fiber Splice Closure GL-D10
This dome-type fiber closure features heat-shrink sealing for 5 cable ports and is suitable for 288 fiber splices.
- Product Introduction
Heatshrink Dome-Type 288 Cores Fiber Splice Closure
The Fiber Splice Closure is widely used to protect fusion splices of two fiber optic cables, or for branch applications from the backbone to premises. According to customized requirements, we can assemble splice trays in our factory to reduce field installation time. This vertical fiber splice closure is constructed from PC (polycarbonate) engineering plastic, featuring waterproof and UV-resistant properties. It is suitable for aerial, duct, or direct buried applications in harsh environments.
The Dome Fiber Splice Closure is designed to house, organize, manage, and protect fiber optic cables and splices. The closure shall be hermetically sealed and provide IP68-rated protection when properly used with the supplied grommets to seal cable entries and exits. The closure is designed to accommodate buffer tube or ribbon fiber splices when the appropriate splice tray is installed. Each unit includes an enclosure dome, the appropriate splice tray organizer, and a grommet kit.
Specifications:
|
Model |
Fiber Splice Closure GL-D10 |
|
Dimension |
490mm×220mm |
|
Capacity |
Bunch: 48-288(cores) Ribbon: up to 864(cores) |
|
Cable entry ports |
5 pieces |
|
Diameter of Cable |
Φ8mm～Φ36 mm |
|
Protection level |
IP68 |
|
Application |
Aerial, Pipeline, Underground, hand-holes |
Features：
• The protection grade reaches IP68.
• Suitable for aerial and wall-mounting.
• The ambient temperature ranges from -40 °C to +65°C.
• The Fiber Splice Closure is compact in size, has high capacity, and enables convenient maintenance.
• The casing is made from high-quality engineering plastics and offers excellent corrosion resistance against acids, alkalis, and salt, as well as anti-aging performance. It also has a smooth appearance and a reliable mechanical structure.
• Its mechanical structure is reliable and is designed to withstand harsh environments, extreme climate changes, and demanding working conditions.
• The splice trays inside are designed like book-style pages that rotate and provide adequate bend radius and space for winding optical fibers, ensuring a minimum bend radius of 40 mm for the fiber. Each optical cable or fiber can be accessed/managed individually.
