FTTH Fiber Optical Distribution Box
Product Model:FTTH Fiber Optical Distribution box GL-A6-24
Working temperature：-40℃~+85℃
Relative humidity：≤85%（+30℃)
Atmospheric pressure：70KPa～106Kpa
Insertion loss：≤0.15dB UPC
return loss：≥50dB
APC return loss：≥60dB
- Product Introduction
GL-A6-24 Fiber Optic Distribution Box
Our 24-core FTTH distribution box with FastConnect tech makes network setup a breeze
Let's talk about what makes the GL-A6-24 special. Basically, this distribution box acts like the central hub for your fiber network. It's where the main feeder cables meet the individual drop cables that run to homes or businesses. Think of it as the traffic controller that makes sure every data packet reaches its destination smoothly.
What's really cool about this enclosure is how it brings everything together in one neat package. You get splicing, splitting, and distribution capabilities all wrapped up in a durable housing that can handle whatever Mother Nature throws at it. Whether you're dealing with scorching heat or freezing cold, this box has got you covered.
Why You'll Love Working With This Box
Built tough
This thing is seriously tough. The PC+ABS construction means it laughs at moisture, dust, and the usual wear-and-tear. With IP65/66 rating, you can install it pretty much anywhere without worrying about the elements.
Everything in One Place
No more running around with multiple boxes. We've packed clamping, splicing, storage, and distribution into this single unit. Your installation crew will thank you for making their jobs so much simpler.
Easy Peasy Maintenance
The flip-up panel design means you can get to what you need without a hassle. Separate pathways keep cables organized and prevent tangles. Maintenance days just got a whole lot easier.
Technical Stuff You Should Know
| Temperature Range | -40°C to +85°C |
| Protection Level | IP65/66 |
| Insertion Loss | ≤0.15 dB |
| Return Loss | ≥50 dB UPC, ≥60 dB APC |
| Safety Features | Lightning protection with ≥3000V DC withstand voltage |
Installation Types
The GL-A6-24 supports both wall-mounted and pole-mounted installation methods, making it suitable for FTTH pre-installation and field deployment scenarios. The design prioritizes user convenience with clear cable management pathways and accessible components that minimize setup time. This adaptability ensures reliable performance whether deployed in controlled indoor environments or challenging outdoor locations.
Wall-mounted Installation
Secure and space-efficient mounting on vertical surfaces, ideal for building basements, corridors, and equipment rooms.
Pole-mounted Installation
Designed for outdoor applications with sturdy mounting brackets that attach securely to telephone poles and utility posts.
Wire Messenger Installation
Suspension installation between poles or structures using messenger wire, providing flexibility in aerial deployments.
Industry application scenarios and solutions
This fiber distribution box is ideal for various FTTx network implementations. Its robust construction and superior sealing capabilities make it suitable for telecommunications infrastructure, data centers, and enterprise networks requiring reliable fiber termination solutions.
Packaging and Handling
The packaging is designed to keep everything safe from moisture and earthquakes. All the accessories come in sealed plastic bags inside boxes that have clear handling instructions. When you're moving these around, just make sure not to turn them upside down or roll them - careful loading prevents bumps and damage.
Try to keep them out of heavy rain before installation, and during transport, keep the temperature between -35°C and +55°C. For storage, stack the cartons in a controlled area away from corrosive gases, with temperatures between -5°C to 45°C and humidity below 70%. This way, everything stays in perfect condition until you're ready to use it.
Service and Support
Thank you for your attention to our products. If you have any questions, we will provide technical support in a timely manner and serve you wholeheartedly.
