Fast Fiber Connector
Model Name: APC/UPC Pre-Polished Fast Fiber Connector
Insertion Loss:0.3dB (Typical); 0.5dB (Max.)
Return Loss:≥50dB (APC)
Operating Wavelength:1260~1650nm
Fiber Type:Single Mode (G.652.D)
- Product Introduction
FTTH SC APC 0.3dB Single Mode Fiber Optic Fast Connector
Innovative Network Integration Platform
Our fast fiber connector are specially designed for high-performance fiber-to-the-home applications. This connector is polished with angular physical contact (APC), ensuring minimal reverse reflection and making it an ideal choice for high-speed data transmission systems. The innovative design enables rapid and reliable on-site termination using standard tools.
Key Features & Advantages
APC polishing technology
With an 8-degree Angle polishing, it minimizes backside reflection and ensures outstanding performance for high-speed data transmission and video applications. This technology provides excellent signal integrity for demanding network environments.
Universal compatibility
Compatible with standard SC adapters and panels to ensure seamless integration with existing infrastructure. Supports various cable types, including flat drip cables and circular indoor/outdoor cables.
Quick termination
Standard tools can be used for rapid on-site installation, reducing deployment time and labor costs. The pre-assembly design eliminates the need for epoxy resin and polishing.
Technical Specifications
| Parameter | Specification | Standards |
|---|---|---|
| Connector Type | SC APC | IEC 61754-4 |
| Insertion Loss | 0.3dB (Typical); 0.5dB (Max.) | GR-326-CORE |
| Return Loss | ≥50dB | IEC 61300-3-6 |
| Operating Temperature | -40°C to +85°C | Telcordia GR-3125 |
| Storage Temperature | -40°C to +85°C | Telcordia GR-3125 |
| Durability | >500 mating cycles | IEC 61753-1 |
| Cable Compatibility | 2.0x3.0mm flat cable, Φ0.9mm/2.0mm/3.0mm round cable | YD/T 1272.4 |
| Fiber Type | Single Mode (G.652.D) | ITU-T G.652 |
Industry application scenarios and solutions
Our fast fiber connector are specifically designed for modern fiber optic networks requiring high performance and reliability. These connectors are ideal for FTTH (Fiber to the Home) deployments, providing the critical connection between the distribution network and customer premises.
In addition to residential applications, these connectors are suitable for FTTB (Fiber to the Building), FTTC (Fiber to the Curb), and 5G fronthaul/backhaul networks. The APC polish makes them particularly well-suited for RF video overlay systems and high-speed data transmission where minimal signal reflection is critical.
The connectors support various installation scenarios including aerial, duct, and direct burial applications. With their robust design and environmental resistance, they maintain stable performance in diverse conditions from controlled indoor environments to harsh outdoor installations.
Quality Assurance and Logistics Management
Every product unit undergoes rigorous testing and quality validation to ensure compliance with international standards and specifications. Our comprehensive technical support network provides expert assistance throughout the product lifecycle.
Service and Support
Thank you for your attention to our products. If you have any questions, we will provide technical support in a timely manner and serve you wholeheartedly.
