Inline Fiber Splice Closure
Model:Inline Fiber Splice Closure
High-performance fiber optic closure with multiple port configurations for FTTH applications. Durable, reliable, and designed for easy installation and maintenance.
- Product Introduction
Horizontal Fiber Optic Closure
High-performance fiber optic closure with multiple port configurations for FTTH applications. Durable, reliable, and designed for easy installation and maintenance.
Our Inline Fiber Splice Closure made of high-quality polycarbonate, it features outstanding impact resistance, UV shielding and heat resistance, capable of withstanding harsh outdoor conditions. Designed specifically for Fiber-to-the-home (FTTH) and broader FTTX applications, its innovative design ensures seamless splicing, termination and distribution, while simplifying installation and maintenance.
Strict industry testing ensures reliability, and there is a 3-year manufacturer's warranty support, which makes you feel more at ease.
Technical Specifications
Below are the detailed technical specifications that make this product stand out in the market
| Product Name | Inline Fiber Splice Closure |
| Type | In-line |
| Application | FTTH, FTTB, FTTX Networks |
| Network Color | Black |
| Dimensions | 510mm (Length) × 230mm (Width) × 130mm (Height) |
| Material | PC (Polycarbonate) |
| Port Configuration | 2/2, 3/3, 4/4 Ports |
| Fiber Core Capacity | 48, 96, 144, 288, 576 Cores |
| Weight | 2.88kg |
| Ingress Protection | IP68 Rated (Dust-tight and Submersible) |
| Operating Temperature | -40°C to +85°C |
| Storage Temperature | -40°C to +85°C |
| Tensile Strength | >1000N |
| Certification | RoHS 2.0 Compliant |
| Warranty Period | 3 Years |
Key Features & Benefits
Easy Installation
Quick and simple installation process with tool-less access for maintenance.
Weather Resistant
IP68 rating ensures protection against dust and water immersion.
High Capacity
Supports up to 576 fiber cores in a compact design.
Reusable
Designed for multiple re-entries without performance degradation.
