Outdoor Fiber Termination Box
Item: Outdoor Fiber Termination Box Drop Cable Storage
Model: GL-2P01B FTTH Fiber Reservation Box
This Fiber Reservation Box offers a perfect cost-effective solution for fiber optic cable coiling.
It coils an outside optical cable up to 30 meters long and works under both indoor and
outdoor environment.
- Product Introduction
This outdoor fiber termination box also called FTTH Fiber Reservation Box, which is a perfect solution for securely storing your cable. It used for fiber optic cable reserved before the FTTH, and compact structure, light weight, mechanical structure design in any operation. The longest fiber optic cable which this fiber storage box can accommodate is 30m. It is safe and convenient it has strong practicability.
Product Details
|
Dimensions and Capability |
||
|
Adapter Capacity |
LC Duplex |
SC Simplex |
|
2 |
1 |
|
|
Dimensions (W*H*D) |
153mm*175mm*42mm |
|
|
Number of Cable Entrance |
Max Diameter 5mm*Q1 |
|
|
Weight |
0.45 KG |
|
|
Optional Accessories |
Adapters, Pigtails, Heat Shrink Tubes |
|
|
Installation |
Wall-Mounted |
|
|
Operation Conditions |
||
|
Temperature |
-40~+85℃ |
|
|
Humidity |
93% at 40℃ |
|
|
Air Pressure |
62kPa – 101kPa |
|
Features for Outdoor Fiber Termination Box
• ABS material used ensures the body strong and light.
• Protective door designed for dust-proof.
• Sealing ring designed for water-proof.
• Easy installations: Ready for wall mount – installation kits provided.
• Cable fixing units provided for fixing optical cable.
• Removable cable entrance.
• Bend radius protected and cable routing paths provided.
• 30 meters long fiber optic cable can be coiled.
• Easy operation: no extra key is needed for closing
• Optional drop cable exit available on the top, side and bottom.
• Optional two fiber splicing available.
Applications for Outdoor Fiber Termination Box
• Widely used in FTTH Access Networks
• Telecommunication Networks
• CATV Networks
• Local Area Networks
