Outdoor Fiber Distribution Enclosure
Product Model:GL-A5-24R Outdoor Fiber Distribution Enclosure
Working temperature：-40℃~+85℃
Relative humidity：≤85%（+30℃)
Atmospheric pressure：70KPa～106Kpa
Insertion loss：≤0.15dB
UPC return loss：≥50dB
APC return loss： ≥60dB
- Product Introduction
GL-A5-24R Fiber Optic Terminal Closure
High-capacity termination solution for FTTx networks with advanced fiber management capabilities
Product Overview
The GL-A5-24R Outdoor Fiber Distribution Enclosure serves as a termination interface in FTTx networks, connecting feeder and drop cables. It enables fiber splicing, splitting, and distribution while providing robust protection and management for network infrastructure.
Fully enclosed structure constructed with PC+ABS material for superior environmental protection
IP65/66 rating ensures complete protection against moisture, water, dust, and aging
Integrated cable management with separate pathways for different cable types
Technical Specifications
Environmental Specifications
Operating Temperature: -40℃ to +85℃
Relative Humidity: ≤85% at +30℃
Atmospheric Pressure: 70kPa to 106kPa
Performance Metrics
Insertion Loss: ≤0.15dB
UPC Return Loss: ≥50dB
APC Return Loss: ≥60dB
Protection Specifications
Insulation Resistance: ≥2×10⁴ MΩ/500V DC
Withstand Voltage: ≥3000V DC/min (no puncture/flashover)
Design Features
The GL-A5-24R Outdoor Fiber Distribution Enclosure integrates clamping mechanisms for feeder and drop cables alongside splicing, fixation, storage, and distribution functions. Separate pathways prevent interference between cables, pigtails, and patch cords. Its flip-up distribution panel and expression port simplify cable placement and maintenance. The unit supports both wall and pole mounting for indoor/outdoor applications.
External View
Internal Layout
Installation Diagram
Installation Types
Wall-mounted Installation
Secure and space-efficient mounting on vertical surfaces, ideal for building basements, corridors, and equipment rooms.
Pole-mounted Installation
Designed for outdoor applications with sturdy mounting brackets that attach securely to telephone poles and utility posts.
Wire Messenger Installation
Suspension installation between poles or structures using messenger wire, providing flexibility in aerial deployments.
Industry application scenarios and solutions
