Splitter Distribution Box
Model: Splitter Distribution Box GL-FDB-24S
Cassette Splitter distribution boxes are used for easy access and distribution of fiber optic connections across networks.
- Product Introduction
Fiber Splitter Distribution Box
The GL-FDB-24S outdoor fiber splitter distribution box is a critical component in FTTx networks, enabling seamless connectivity between feeder/distribution cables and subscriber drop cables. Designed for wall or pole installation, this rugged unit features three input ports and sixteen output ports on the bottom panel, ensuring scalable signal distribution. Its dual-tray structure enhances operational efficiency: the rear tray supports feeder cable splicing using pigtails or splitters, while the front tray streamlines subscriber connections through a versatile adapter plate. Built for durability, the UV- and water-resistant housing combines high-quality plastic with a rubber gasket to protect against harsh outdoor conditions.
Highly adaptable to various connector types, the GL-FDB-24S excels in FTTH deployments, telecommunication networks, CATV systems, and data/LAN infrastructures. Its modular design simplifies maintenance and upgrades while supporting efficient fiber management in space-constrained environments. By combining robust environmental protection with flexible configuration options, this distribution box ensures reliable signal transmission and long-term network performance, making it ideal for expanding optical connectivity in both urban and rural deployments.
Specifications:
|
Item Name |
Splitter Distribution Box GL-FDB-24S |
|
Size |
252x210x72 mm |
|
IP Rate |
IP65 |
|
Material |
PC+ABS |
|
Port |
3 pcs Φ16mm cable inlet 16 pcs for 2x3mm drop cable outlet |
|
Max capacity |
24F |
|
Adapter type |
SC, LC |
|
Max ratio |
Max 1:16 |
|
Installation method |
Wall and pole mount |
Features:
• Designed for interior or exterior environments with UV-resistant and weatherproof construction
• Integrated security lock and pre-printed identification markers provided
• Features industry-standard connectors with durable PC/ABS polymer composite housing
• Compatible with multiple splitter configurations including 1×4/8/16 and 2×4/8/16 modules
• Supports 16 FTTH connections (requires fiber optic adapters available separately)
• 24 fusion splice capacity for network expansions
• Dual mounting options for vertical surfaces or utility poles
• Connectivity includes 3 input ports and 16 output terminals
• Flexible installation through versatile mounting configurations
• Complies with RoHS environmental standards for hazardous substance control
Applications:
• Fiber Splitter Distribution Box: Key Applications
A Fiber Splitter Distribution Box is essential in fiber optic networks for splitting and distributing optical signals efficiently. It is widely used in FTTH (Fiber-to-the-Home) systems, telecom networks, and data centers to manage multiple connections from a single fiber source. This device ensures organized signal distribution while protecting delicate fiber splices and connectors.
• Enhancing Network Flexibility and Scalability
The box supports network scalability by enabling easy integration of splitter modules, allowing seamless expansion of user connections. Its rugged design protects against environmental factors, making it suitable for indoor and outdoor installations. This flexibility is critical for telecom operators and ISPs aiming to deliver high-speed broadband services.
