FC Adapter
Model: FC Adapter Transparent With Flange
Adapter Type: FC
Body Style: Simplex
Insertion Loss: ≤0.2dB
Durability: >1000times
Mounting Type: Without Flange
Aligment Sleeve Material: Ceramic
Material: Metal RoHS Compliancy
Status: Compliant
- Product Introduction
FC Adapter Transparent With Flange

Introduction.
The FC Adapter has become an indispensable component in optical fiber communication through metal structure reinforcement, end face optimization design and support for multiple types of interfaces. Its low loss, high durability and wide compatibility have enabled it to occupy an important position in fields such as telecommunications, data centers and industry.
Features.
The low-loss feature of the FC Adapter stems from the precise grinding process , and its insertion loss can be controlled within ≤0.2dB, effectively ensuring the efficient transmission of optical signals. Meanwhile, high compatibility enables conversions like FC-SC/FC-LC, boosting system flexibility for diverse connections. Strong environmental adaptability stems from its -40°C to 85°C wide temperature range and corrosion-resistant design, ensuring stable operation in industrial/outdoor/extreme temp-humidity environments with minimal performance fluctuations.

Our Product



Product Specification.
| parameter | FC Adaptor | |||
| SM | MM | |||
| PC | UPC | APC | PC | |
| Insertion loss | ≤0.2dB | ≤0.2dB | ≤0.2dB | ≤0.2dB |
| Alternationg loss | ≤0.2dB | |||
| Repeatability | ≤0.2dB | |||
| Durability | The change of 1000 interpolation times is less than 0.2dB | |||
| Working temperature | -40~85°C | |||
| Storage temperature | -40~85°C | |||
Industry application scenarios and solutions
