PA-06 Optic Cable Tension Clamp
Model: PA-06 Optic Cable Tension Clamp
Materia:l UV resistant thermoplastic,aluminum stainless steel,
Loop Type: stainless steel(zinc)
Cable OD (mm): 3-6
MTL (kN): 3
Span (m): 60-80
- Product Introduction
PA-06 Anchor Tension Clamp
PA-06 Optic Cable Tension Clamp features a robust thermoplastic body engineered for high mechanical and climatic resistance, paired with an internal sheath containing one or two insulating plastic wedges to securely clamp the neutral messenger cable without compromising insulation integrity.
Two stainless steel bail ends act as locking mechanisms, enabling rapid deployment through a simple push-pull motion-wedges retract effortlessly for easy installation. The integrated flexible steel loop ensures compatibility with closed-eye brackets, offering a streamlined solution for overhead line anchoring in power transmission or telecom applications.
Our products
Installation Technology.
The PA-06 Optic Cable Tension Clamp features a modular design, installed in pairs at cable terminations, mid-span intervals (every 5 supports), and critical stress points.
This standardized layout adapts to diverse stress scenarios while enabling rapid on-site assembly through snap-in components, significantly reducing manual operational complexity compared to traditional multi-part systems.
Performance and Application Value.
Its core advantage lies in the wedge engagement pre-tensioning mechanism and balanced load distribution design. By leveraging wedge-driven clamping forces and uniform stress dispersion, the clamp reduces suspension time by over 30% versus conventional methods.
This efficiency, combined with robust corrosion resistance and vibration resistance, makes it ideal for power transmission lines and telecom infrastructure, where rapid deployment and long-term reliability are critical.
Application
Choose the plan that suits you best.
FTTH Networks
Acts as a terminal point for feeder-to-drop cable transitions, enabling high-speed broadband and IPTV services in residential and commercial areas.
01
5G Base Stations
Supports backhaul connectivity for 5G deployments, ensuring low-latency signal distribution.
02
CATV & Broadband Systems
Integrates with CATV networks for hybrid fiber-coaxial (HFC) architectures, delivering video and data services
03
Industrial & Remote Areas
Used in factories, transportation hubs, and rural regions where environmental resilience is critical.
04
